Your present position： Home > Products > Other Equipment > DetailsGF-200 wrinkling machine
Cylinder Size:φ1400×1070mm Speed:28r/min
Rated Loading: 90kg
Main Motor Power: 2.2kw
Ventilator Motor Power: 2.2kw
Steam Pressure: 0.4-0.6Mpa Compress Air Pressure: 0.4-0.6Mpa
Dimension: 2100×1530×2550mm
Weight:900kg
This GF-200 wrinkling machine is good use for PVC leather. It’s a modernized device for leather factory.
Cylinder Size | φ1400x1070mm |
Drum Speed | 28r/min |
Rated Load | 90kg |
Main MotorPower | Y112M-6 2.2KW |
Blower Motor | Y100L-6 2.2KW |
Heat Collecting Tank Pressure | 0.4-0.6Mpa |
Compressed Air Pressure | 0.4-0.6Mpa |
Diamension | 2100x1530x2550mm |
Net Weight | 900kg |
